Fox Blocks Insulated Concrete Forms-ICF Wall Panels

construction site using insulated concrete wall forms

Advantages

● Impact Resistant

● Environmentally Friendly

● Engineered to withstand 200 mph winds or higher

● Reinforced concrete

● Tornado Resistant

● Hurricane Resistant

● Flood Resistant

● Fireproof

● Earthquake Resistant

● 500 year warranty

Fox Blocks Insulating Concrete Form Wall Systems provide an extremely energy efficient building envelope offering superior strength, sound, air quality, and well insulated walls. Fox Blocks ICF building blocks is a division of Airlite Plastics Company, The Company produces roughly 1.6 billion molded units a year.

Products

● Straight Block

● Angle Block

● Corner Block

● T-Block Block

● Taper Block

● Ledge Block

● Radius Block

● Curb Block

The T-Block (Short Leg) typically makes up 1-2% of the ICF wall assembly on most residential & commercial jobs. This block has eight (8) strong full length injection molded plastic ties made from Polypropylene (PP)regrind resin that are well marked with the word "Fox Blocks" located on all sides of the block. These ties secure the three pieces of 1.5 pcf density modified Expanded Polystyrene (EPS) foam together that makes up each block type.

The Corbel Ledge Block typically makes up 1-2% of the ICF wall assembly on most residential & commercial jobs. Corbel Ledge Blocks are typically used at the top of the wall to support other adjacent lateral loads (i.e., exterior masonry veneer loads, interior floor joist loads, etc.). Once a single layer or course of Corbel Ledge Blocks is installed, horizontal reinforcing steel bars are inter-locked securely together in the ties of the blocks, in both the main core and the extended ledge core.

The Taper-Top Block typically makes up 1-2% of the ICF wall assembly on most residential & commercial jobs. This block has six (6) strong full length injection molded plastic ties made from Polypropylene (PP)regrind resin that are well marked with the word "Fox Blocks" located on both sides of the block. These ties secure the two pieces of 1.5 pcf density modified Expanded Polystyrene (EPS) foam together that makes up each block type.
